Hardware that works where you play.
Eight concept designs with target specifications, built for heat, dust, back-to-back fixtures and patchy signal. None are on sale. Each is designed to record offline, sync when it can and write to the athlete's record.
Rovify Capture Flex
A two-lens camera that goes up on a tripod at the sideline, films the whole pitch or court, follows the play and clips the highlights on the device.
| Size | 200 × 85 × 100 mm |
|---|---|
| Capture | 2 × 4K corner lenses, each angled 38° outward |
| Processing | On-device AI: ball and player tracking, auto-highlights |
| Controls | Start button with status beacon · red recording light |
| Power | USB-C PD under a sealed flap |
| Mount | Standard tripod thread · carry handle |
Rovify Capture Outdoor
A sealed three-lens camera on a pole that records and streams every scheduled fixture with nobody on site, powered by the sun or by one network cable.
| Size | ≈ 300 × 110 × 130 mm (proposed) |
|---|---|
| Capture | 3 × 4K: one facing the pitch, two angled 40° outward |
| Housing | IP66 · gasketed shell · sun shield · rear heatsink |
| Power | Solar panel with battery, or PoE+ |
| Install | Pole clamp with tilt arm · surge protector |
| Streaming | Scheduled recording, auto-publishes to Rovify TV |
Rovify Capture Indoor
A ceiling camera for basketball, volleyball, handball and futsal halls. Four lenses look down at the court so every game is filmed without anyone setting up.
| Size | ≈ 260 × 225 × 75 mm (proposed) |
|---|---|
| Capture | 4 × 4K lenses, angled down about 35° |
| Rating | IP4x |
| Power | PoE+ |
| Mount | Ceiling drop rod or flush plate |
| Sports | Basketball, volleyball, handball, futsal |
Rovify Capture Point
A round six-sensor station for stadiums and multi-pitch venues that sees in every direction from one mounting point, on a pole or under a roof.
| Size | ≈ Ø 240 × 150 mm (proposed) |
|---|---|
| Capture | 6 × 4K sensors behind one glass band |
| Processing | 2 × Capture Core |
| Housing | IP66 · drip lip over the glass · pressure vent |
| Power | PoE++ |
| Mount | Pole top or ceiling |
Rovify Track One
A sealed tracking module that clips to the waistband and measures distance, speed, sprints and load for every athlete in the session.
| Size | 60 × 45 × 15 mm |
|---|---|
| Positioning | 10 Hz GNSS (GPS, Galileo, GLONASS, BeiDou) |
| Motion | 400 Hz accelerometer and gyroscope |
| Housing | Sealed shell · IP67 target |
| Charging | 4 pogo contacts, no open ports |
| Wear | Spring clip |
Rovify Track Titan
A mesh vest that carries the Track One module between the shoulder blades, with a chest pod for heart rate, for full-session performance data.
| Module | Track One, in a pocket between the shoulder blades |
|---|---|
| Heart rate | Chest ECG pod on a strap |
| Vest | Breathable mesh · 5 sizes · machine washable |
| Sync | Through the coach's phone |
Rovify Track Dock
A desktop dock that charges a whole squad's trackers between sessions and uploads their data over Wi-Fi while they charge.
| Size | ≈ 600 × 200 × 140 mm (proposed) |
|---|---|
| Bays | 30, in three stepped rows, with a charge light on each |
| Charging | Pogo pins |
| Upload | Wi-Fi bulk upload · Ethernet |
| Power | USB-C PD or DC in |
Rovify Track Case
A rugged case that carries 30 trackers to away fixtures, charges them with the lid closed from its own battery and uploads their data over Wi-Fi.
| Size | ≈ 480 × 410 × 175 mm (proposed) |
|---|---|
| Bays | 30, numbered, on pogo pins |
| Battery | Built in · charges closed · 5-light gauge on the front |
| Upload | Wi-Fi |
| Build | Hard shell · latches with padlock loops · pressure valve |
